Display 2-inch black and white LCD screen, resolution 128*64

Installation method Thread installation/flange installation

Protection class IP65

Measurement variable level/distance measurement range O~5M/0~10M measurement accuracy ±0.5%FS

Resolution 1mm or 0.1%FS (take the maximum value)

Temperature compensation Automatic temperature compensation, with temperature calibration function Working environment temperature 0~50°C

Storage ambient temperature -20~70°C

Relative humidity (10~85)%RH (no condensation) language

Chinese/English

Power supply 14~28VDC
